Cat. No. M1783
SB590885 Structure
Size Price Availability Quantity
10mg USD 155 In stock
50mg USD 615 In stock
100mg USD 990 In stock
Free Delivery on orders over USD 500 Bulk Inquiry?

Quality Control
Biological Activity

SB-590885 is a selective small-molecule inhibitor of the B-Raf kinase and Ki app values are 0.16 and 1.72 nM for B-Raf and c-Raf respectively. SB590885 has been used to overcome the dependence of MAPK signaling and tumor cell growth on BRaf kinase activity. In melanoma and colorectal cancer cell lines with B-Raf V600E mutation, an effective inhibition of cell proliferation was achieved at concentrations that blocked ERK phosphorylation. The inhibition of MAP kinase is one of the vital ways to get rid of un-wanted tumor growth. SB590885 also act as an angiogenesis inhibitor and also helps in the research studies of different  important kinase pathways.

Customer Product Validations & Biological Datas
Source J Cell Mol Med (2015). Figure 2. SB590885
Method MTT assay
Cell Lines TT cells
Concentrations 0.01–100 μM
Incubation Time 72 hrs
Results RAF265 was the most effective compound, showing an IC50 = 0.09 μM, while SB590885 showed an IC50 = 3.36 μM, and ZSTK474 an IC50 = 0.59 μM
Cell Experiment
Cell lines Colo205, HT-1080, HT-29, A395p and SK-MEL28 cells line
Preparation method Cellular assays.
For proliferation assays, cells were treated with compounds in 0.1% DMSO and incubated for 72 hours at 37°C, 5% CO2. Viable cells were quantified using CellTiter-Glo reagent (Promega, Madison, WI) and luminescence detection on a Victor 2V plate reader (Perkin-Elmer, Turku, Finland). Cells were prepared for cell cycle analysis on a Becton Dickinson FACScan, according to the manufacturer's instructions. Data was acquired and analyzed using CellQuest v3.3 software. Anchorage-independent growth assays were done as described elsewhere ( 6), with inhibitors or DMSO vehicle included in the agar layer. Cultures were re-fed with media and inhibitor or DMSO every 5 to 7 days for a total of 28 days. Colonies were visualized and photographed by conventional light microscopy and quantified by counting on a grid in triplicate.
Concentrations 0.1, 1 and 10 μ M
Incubation time 72 h
Animal Experiment
Animal models A375P xenograft model
Formulation 2% N,N-dimethylacetamide, 2% Cremophor EL, and 96% acidified water (pH ∼4-5)
Dosages 50 mg/kg daily for 21 days
Administration i.p.
Conversion of different model animals based on BSA (Value based on data from FDA Draft Guidelines)
Species Mouse Rat Rabbit Guinea pig Hamster Dog
Weight (kg) 0.02 0.15 1.8 0.4 0.08 10
Body Surface Area (m2) 0.007 0.025 0.15 0.05 0.02 0.5
Km factor 3 6 12 8 5 20
Animal A (mg/kg) = Animal B (mg/kg) multiplied by  Animal B Km
Animal A Km

For example, to modify the dose of resveratrol used for a mouse (22.4 mg/kg) to a dose based on the BSA for a rat, multiply 22.4 mg/kg by the Km factor for a mouse and then divide by the Km factor for a rat. This calculation results in a rat equivalent dose for resveratrol of 11.2 mg/kg.

Chemical Information
Molecular Weight 453.54
Formula C27H27N5O2
CAS Number 405554-55-4
Purity 99.86%
Solubility DMSO 5 mg/mL
Storage at -20°C

The identification of potent, selective and CNS penetrant furan-based inhibitors of B-Raf kinase.
Takle AK, et al. Bioorg Med Chem Lett. 2008 Aug 1;18(15):4373-6. PMID: 18621524.

Demonstration of a genetic therapeutic index for tumors expressing oncogenic BRAF by the kinase inhibitor SB-590885.
King AJ, et al. Cancer Res. 2006 Dec 1;66(23):11100-5. PMID: 17145850.

Related Raf Products

PLX7904, also known as PB04, is a potent and selective paradox-breaker RAF inhibitor.


PLX8394 is an orally bioavailable, potent and selective Raf inhibitor with IC50 of 5 nM.


B-Raf-IN-1 (MDK36057) is a potent b-Raf inhibitor with IC50 of 24 nM.


RAF709 is a novel Raf kinase inhibitor with IC50 values of 0.4 and 1.5 nM for c-Raf and b-Raf, respectively.


L-779450 is a potent, ATP-competitive Raf kinase inhibitor (IC50 =10 nM) that displays > 7, > 30 and > 70-fold selectivity over p38α, GSK3β and Lck respectively.
