Cat. No. M1873
LDN-193189 Structure


Size Price Availability Quantity
Free Sample (0.5-1 mg)  USD 0 In stock
10mg USD 140 In stock
50mg USD 400 In stock
Free Delivery on orders over USD 500 Bulk Inquiry?

Quality Control
Biological Activity

LDN-193189 is a highly potent small molecule inhibitor of bone morphogenetic protein (BMP) type I receptors ALK2 and ALK3 with IC50 values of 5 nM and 30 nM, respectively. BMPs induce Smad1/5/8 plus non-Smad pathways, such as MAPK and Akt. BMP signaling pathway is the key regulators of cell fate decisions during embryogenesis and tissue homeostasis. LDN-193189 inhibits ectopic ossification and a potential agent in the treatment of NSCLC lung tumors, showing significant in vivo clinical utility. In addition, it inhibits the activation of p38, ERK1/2 and Akt in C2C12 cells. LDN-193189 only weakly inhibits ALK4, ALK5, and ALK7. LDN-193189 affects not only the Smad but also the non-Smad signalling pathways induced by either BMP2, BMP6 or GDF5.

Customer Product Validations & Biological Datas
Source J Biol Chem (2015). Figure 4. LDN-193189
Method immunoblotting
Cell Lines C2C12 cells
Concentrations 5 μM
Incubation Time 30 min
Results Pretreatment with dorsomorphin or LDN-193189 led to reduced levels of phosphorylated Smad2/3 following GDF8 stimulation (Fig. 4A), which were comparable with their effects on BMP2-induced phosphorylation of Smad1/5 (Fig. 4B), whereas there was no effect on TGF- induced Smad2/3 signals (Fig. 4A).
Source J Biol Chem (2015). Figure 2. LDN-193189
Method immunoblotting
Cell Lines C2C12 cells
Concentrations 0.5 μM
Incubation Time 30 min
Results A similar effect of dorsomorphin and LDN-193189 treatment was observed in undifferentiated primary human myoblasts as well as in the mouse myoblast cell line C2C12
Cell Experiment
Cell lines C2C12 cells
Preparation method Alkaline phosphatase activity We seeded C2C12 cells into 96-well plates at 2,000 cells per well in DMEM supplemented with 2% FBS. We treated the wells in quadruplicate with BMP ligands and LDN-193189 or vehicle. We collected the cells after 6 d in culture in 50 μl Tris-buffered saline and 1% Triton X-100. We added the lysates to p-nitro-phenylphosphate reagent in 96-well plates (Sigma) for 1 h and then evaluated alkaline phosphatase activity (absorbance at 405 nm). We measured cell viability and quantity by Cell Titer Aqueous One (absorbance at 490 nm, Promega), using replicate wells treated identically to those used for alkaline phosphatase measurements.
Concentrations 0,2,8,31,125,500nM
Incubation time 6 days
Animal Experiment
Animal models C57BL/6 mouse FOP model
Formulation unknown
Dosages 3 mg /kg every 12 h
Administration intraperitoneally
Conversion of different model animals based on BSA (Value based on data from FDA Draft Guidelines)
Species Mouse Rat Rabbit Guinea pig Hamster Dog
Weight (kg) 0.02 0.15 1.8 0.4 0.08 10
Body Surface Area (m2) 0.007 0.025 0.15 0.05 0.02 0.5
Km factor 3 6 12 8 5 20
Animal A (mg/kg) = Animal B (mg/kg) multiplied by  Animal B Km
Animal A Km

For example, to modify the dose of resveratrol used for a mouse (22.4 mg/kg) to a dose based on the BSA for a rat, multiply 22.4 mg/kg by the Km factor for a mouse and then divide by the Km factor for a rat. This calculation results in a rat equivalent dose for resveratrol of 11.2 mg/kg.

Chemical Information
Molecular Weight 406.48
Formula C25H22N6
CAS Number 1062368-24-4
Purity 99.93%
Solubility Water ≥30 mg/mL
Storage at -20°C
Related ALK Products

TPX-0005 is a potent ALK/ROS1/TRK inhibitor, with IC50 of 5.3 nM, 1.01 nM, 1.26 nM and 1.08 nM for SRC, WT ALK, ALK G1202R and ALK L1196M, respectively.

LDK378 dihydrochloride

LDK378 2Hcl (Ceritinib) is potent inhibitor against ALK with IC50 of 0.2 nM, shows 40- and 35-fold selectivity against IGF-1R and InsR, respectively.

Entrectinib (RXDX-101)

Entrectinib (RXDX-101) is an orally bioavailable pan-TrkA/B/C, ROS1 and ALK inhibitor with IC50 ranging between 0.1 and 1.7 nM. Phase 2.

Crizotinib hydrochloride

Crizotinib is inhibitor of the c-Met kinase and the NPM-ALK. Crizotinib inhibited cell proliferation in ALK-positive ALCL cells (IC50s=30 nM). Crizotinib is useful in treatment of anaplastic large-cell lymphoma.


Brigatinib (AP26113) is a potent and selective ALK (IC50, 0.6 nM) and ROS1 (IC50, 0.9 nM) inhibitor. It also inhibits ROS1, FLT3, and mutant variants of FLT3 (D835Y) and EGFR with lower potentcy.
